GV-GDR2801

ModelGV-GDR2801-2FGV-GDR2801-3F
IrisFixedFixed
Focal Length (mm)2.8mm3.6mm
Horizontal FOV107°89°
Maximum ApertureF/1.6F/1.6
Image Format1/2.8″1/2.8″
Rated 0 out of 5
GV-GDR2801

Description

AI 2MP H.265 Super Low Lux WDR Pro IR Mini Fixed Rugged IP Dome

AI Deep-Learning IP Camera

GV‐GDR2801 is a 2 MP outdoor mini fixed rugged IP Dome. The camera supports H.265 video codec to achieve a better compression ratio while maintaining high-quality pictures at reduced network bandwidth. GV‐GDR2801 adheres to IP67 and IK10 standards and can be powered through PoE.

Empowered by deep learning algorithms, AI technology distinguishes humans and vehicles from other moving objects. Integrated with GeoVision Video Management Software (GV-VMS), it supports AI perimeter protection, real-time alert, playback, and more.

    Key features

    • AI deep learning: AI Perimeter Protection & Classification (Human, Vehicle)
    • 1/2.8″ progressive scan CMOS sensor
    • Triple streams from H.265, H.264 or MJPEG
    • Min. illumination at 0.008 lux
    • Up to 30 fps at 1920 x 1080
    • Intelligent IR
    • Wide Dynamic Range Pro (WDR Pro)
    • IR distance up to 30 m (100 ft)
    • Ingress protection (IP67)
    • Vandal resistance (IK10 for metal casing)
    • 3-axis mechanism (pan / tilt / rotate)
    • DC 12V / PoE (IEEE 802.3af)
    • Built-in microSD card slot (SD / SDHC / SDXC) for local storage
    • One-way audio capable
    • 3D noise reduction
    • AI analytics (Line Crossing, Region Intrusion)
    • Motion detection
    • Text overlay
    • Privacy mask
    • ONVIF (Profile G, S, T, M) conformant
    • 20 languages supported

      Overview

        Accessories

        Model NoNameDetails
        GV-Mount211-4Wall Mount BracketDimensions: 129.5 x 155 x 74.5 mm (5.10″ x 6.10″ x 2.93″)
        Weight: 0.527 kg (1.16 lb)
        GV-Mount211-6Wall Mount BracketDimensions: 199 x 139.3 x 140.6 mm (7.83″ x 5.48″ x 5.54″)
        Weight: 0.56 kg (1.23 lb)
        *must be used with Mount506
        GV-Mount314Corner Mount BracketDimensions: 215 x 121.4 x 215 mm (8.46 x 4.78 x 8.46 in)
        Weight: 2.05 kg (4.52 lb)
        *must be used with Mount211-6
        GV-Mount470Pole Mount BracketDimensions: 163.3 x 54.5 x 215 mm (6.43″ x 2.15″ x 8.46″)
        Weight: 1.10 kg (2.43 lb)
        *must be used with Mount211-6
        GV-Mount506Junction BoxDimensions: Ø 139.3 x 171.6 x 50 mm (Ø 5.48″ x 6.76″ x 1.97″)
        Weight: 0.51 kg (1.13 lb)
        GV-Mount507-1Junction BoxDimensions: Ø 111.7 x 55 mm (Ø 4.40″ x 2.17″)
        Weight: 0.33 kg (0.73 lb)
        GV-PA191PoE AdapterGV-PA191 is a Power over Ethernet (PoE) adapter designed to provide power to the IP device through a single Ethernet cable.
        GV-PA301Gigabit PoE AdapterGV-PA301 is a Gigabit Power over Ethernet (PoE) adapter.
        GV-POE SwitchGV-POE Switch is designed to provide power along with network connection to IP devices. It is available in various models with different numbers and types of ports.
        Power AdapterContact our sales representatives for the countries and areas supported.

          Packing List

          • GV-GDR2801 Mini Dome
          • Waterproof Rubber Set
          • Screw Kit
          • Drill Template Paster
          • Hex Key
          • Download Guide
