GV-GEBF4802

Model: GV-GEBF4802

AI deep learning: AI Perimeter Protection & Classification (Human, Vehicle) 1/3″ progressive scan CMOS sensor Triple streams from H.265, H.264 and MJPEG Min. illumination at 0.005 lux Up to 30 fps at 2560 x 1440 Intelligent IR Smart Warm LED…

Wide Dynamic Range Pro (WDR Pro)IR distance up to 30 m (100 ft)Ingress protection (IP67)Vandal resistance (IK10 for metal casing)3-axis mechanism (pan / tilt / rotate)DC 12V / PoE (IEEE 802.3af)

Price

Project-based quote

◈ Integrated solution

Request a Quote ⤓ Downloads

4MP H.265 Super Low Lux WDR Pro Full Color Warm LED IR Eyeball Dome IP Camera

AI Deep-Learning IP Camera

GV‐GEBF4802 is a 4 MP outdoor eyeball dome IP camera, equipped with a smart warm LED for full color surveillance during nighttime. The camera supports H.265 video codec to achieve a better compression ratio while maintaining high-quality pictures at reduced network bandwidth. GV‐GEBF4802 adheres to IP67 and IK10 standards and can be powered through PoE.

Empowered by deep learning algorithms, AI technology distinguishes humans and vehicles from other moving objects. Integrated with GeoVision Video Management Software (GV-VMS), it supports AI perimeter protection, real-time alert, playback, and more.

This camera model (GV-GEBF4802-2F) is available in two colors: White and Charcoal.

Models

Model	GV-GEBF4802-2F	GV-GEBF4802-3F
Iris	Fixed	Fixed
Focal Length (mm)	2.8mm	3.6mm
Horizontal FOV	94°	78°
Maximum Aperture	F/1.6	F/1.6
Image Format	1/3″	1/3″

✓Wide Dynamic Range Pro (WDR Pro)
✓IR distance up to 30 m (100 ft)
✓Ingress protection (IP67)
✓Vandal resistance (IK10 for metal casing)
✓3-axis mechanism (pan / tilt / rotate)
✓DC 12V / PoE (IEEE 802.3af)
✓Built-in microSD card slot (SD / SDHC / SDXC) for local storage
✓Built-in microphone
✓3D noise reduction
✓AI analytics (Line Crossing, Region Intrusion)
✓Smart lighting switch between IR LED (for motion detection) and Warm LED (for people, vehicle and motorcycle detection)
✓Motion detection
✓Text overlay
✓Privacy mask
✓ONVIF (Profile G, S, T, M) conformant
✓21 languages supported

▣GV-GEBF4802 Eyeball Dome
▣Waterproof Rubber Set
▣Screw Kit
▣Drill Template Paster
▣Download Guide

Model	GV-GEBF4802-2F
Iris	Fixed
Focal Length (mm)	2.8mm
Horizontal FOV	94°
Maximum Aperture	F/1.6
Image Format	1/3″
